Recent Posts
1
Tech Talk / Re: Avenza Maps
« Last post by cLAY on Yesterday at 11:28:44 AM »FYI the Ghost and Mclean links no longer work.
2
Tech Talk / Re: AMC 360 misfire
« Last post by cLAY on Yesterday at 11:26:07 AM »Is the carb new(fairly new)? Not something bought 2nd hand? If so the throttle plates should be set correctly and I would avoid playing with them as that would add a whole new set of parameters to the mix.
A vacuum guage lets you see whats going on as you drive, not as accurate as a O2 sensor but still handy and easier, also handy to watch while adjusting at idle and a fairly cheap.
Is your vaccum advance hooked to ported or manifold? Did you disconnect and plug it when setting the timing? If not then you might not have enough base advance timing. If you are not sure the difference on ported vs manifold then do a google search, easy to find.
A vacuum guage lets you see whats going on as you drive, not as accurate as a O2 sensor but still handy and easier, also handy to watch while adjusting at idle and a fairly cheap.
Is your vaccum advance hooked to ported or manifold? Did you disconnect and plug it when setting the timing? If not then you might not have enough base advance timing. If you are not sure the difference on ported vs manifold then do a google search, easy to find.
3
Land Issues, Trail Projects & Trail Stewardship / 2021-22 Sport Fishing Engagement Survey and Webinars
« Last post by Tee-Hee on January 17, 2021, 10:29:44 AM »From Trails 4 Tomorrow’s Facebook page:
Conservation and management of fish population can impact our ability to maintain and build trails. Alberta Environment and Parks is engaging Albertans with a survey (open until February 8, 2021 until 9:00am) and webinars.
https://www.alberta.ca/2021-22-sportfishing-regulations-engagement.aspx
For more information regarding relevant legislation please go to our Resource page (https://www.trails4tomorrow.ca/resources) where you can read the Species at Risk Act and Fisheries Act amongst others.
Conservation and management of fish population can impact our ability to maintain and build trails. Alberta Environment and Parks is engaging Albertans with a survey (open until February 8, 2021 until 9:00am) and webinars.
https://www.alberta.ca/2021-22-sportfishing-regulations-engagement.aspx
For more information regarding relevant legislation please go to our Resource page (https://www.trails4tomorrow.ca/resources) where you can read the Species at Risk Act and Fisheries Act amongst others.
4
Tech Talk / Re: AMC 360 misfire
« Last post by Zooguy on January 13, 2021, 07:14:27 PM »I didn’t think of an O2 sensor. It sounds like it would help to dial it in only if I know what’s wrong. I’ve been told that maybe I have to adjust the butterfly valves on the bottom of the carb if my idle screws are going all the way in without stalling. Also I’m not sure if my choke is set properly. A gauge wouldn’t tell me what’s wrong, only that something is wrong. Those are just my initial thoughts so I will research a bit and get a better understanding.
I have an electrical choke on the side of the carb.
The timing was set at Idle and might be between 6-8. We didn’t check it at higher rpms.
It does have the AMC 20 in it. I checked the gears and it looks like it has 273 open, with T5 and 35’s. I don’t mind the gears since it will mainly be on the road. But I might change to 33s once the 35s wear down. They are brand new so that will be a while.
Thanks again for the suggestions, I will research a bit and DM you for some help if I can’t get it right soon.
I have an electrical choke on the side of the carb.
The timing was set at Idle and might be between 6-8. We didn’t check it at higher rpms.
It does have the AMC 20 in it. I checked the gears and it looks like it has 273 open, with T5 and 35’s. I don’t mind the gears since it will mainly be on the road. But I might change to 33s once the 35s wear down. They are brand new so that will be a while.
Thanks again for the suggestions, I will research a bit and DM you for some help if I can’t get it right soon.
5
Tech Talk / Re: AMC 360 misfire
« Last post by renegade350 on January 13, 2021, 01:34:45 PM »With my holly truck avenger on an older 350, I get an annoying idle miss fire with the idle screws 1/16" of a turn either direction from being perfectly bang on. I highly recommend a wideband O2 sensor with an A/F gauge, tuning a carb without one is a lost art, even going off of feel/RPM I was still way out until I used the gauge. going from a 10 to 13.5 mixture will give you almost 1/3 better fuel economy. The gauge will pay for itself x5 easily in fuel consumption and unnecessary stress after a few big trips. (Going from 5-8 mpg to almost 12).
It will also help diagnose future carb / engine problems including vacuum leaks, stuck chokes, clogged fuel filters, flooding, stumbles during power transitions (coasting to power), stumbles at 10-100% throttle, fine tuning the accelerator pumps and secondary's, backfires etc.
https://www.amazon.ca/AEM-30-4110-UEGO-Ratio-Gauge/dp/B00N3VGPYS/ref=asc_df_B00N3VGPYS/?tag=googleshopc0c-20&linkCode=df0&hvadid=292977936168&hvpos=&hvnetw=g&hvrand=6573167427041104759&hvpone=&hvptwo=&hvqmt=&hvdev=c&hvdvcmdl=&hvlocint=&hvlocphy=9001313&hvtargid=pla-377903111462&psc=1
You need to be completely at 185F engine temp or hotter to accurately tune anything. Is this an electric choke or mechanical? you didn't mention this at all in your previous posts. If electrical, and it dies after 10 min it may not be opening causing a rich situation - possible electrical issue but incredibly easy to fix properly or just with a zip tie to troubleshoot. I doubt it is anything else electrical, as they really only need two hot wires to work - 12 volt ignition to the distributor and starter crank power, the rest are just accessories. It could also be the speed the choke is opening, possibly to soon? Adjusted by turning the black disk on the side clockwise or counterclockwise.
Timing is at 8....that's 8 degrees with no vac advance or total? Idle total advance, vac + mech should be in the 25-40* range, usually the more the better, I dont know offhand what a 360 and your cylinder heads like but in that range.
even if there is a huge vacuum leak, the miss should go away at WOT / zero vacuum.
Keep in mind;
Idle screws are idle af ratio
mid range power is primaries and the idle mixture together. Not just primaries.
WOT is idle mixture + primaries + secondary's. All three combined, plus the accelerator pumps if you really got on it.
A properly tuned 360 should be able to really test your AMC 20 2 piece axle strength on pavement if you still have that rear-end.
My services can be available with a complete holly jet kit, timing lights, vac gauges etc for a small fee
plus I cant even remember what a CJ7 is supposed to look like anymore. I have spent enough time and money tuning a carb I could have changed over to fuel injection now but that's another story.
It will also help diagnose future carb / engine problems including vacuum leaks, stuck chokes, clogged fuel filters, flooding, stumbles during power transitions (coasting to power), stumbles at 10-100% throttle, fine tuning the accelerator pumps and secondary's, backfires etc.
https://www.amazon.ca/AEM-30-4110-UEGO-Ratio-Gauge/dp/B00N3VGPYS/ref=asc_df_B00N3VGPYS/?tag=googleshopc0c-20&linkCode=df0&hvadid=292977936168&hvpos=&hvnetw=g&hvrand=6573167427041104759&hvpone=&hvptwo=&hvqmt=&hvdev=c&hvdvcmdl=&hvlocint=&hvlocphy=9001313&hvtargid=pla-377903111462&psc=1
You need to be completely at 185F engine temp or hotter to accurately tune anything. Is this an electric choke or mechanical? you didn't mention this at all in your previous posts. If electrical, and it dies after 10 min it may not be opening causing a rich situation - possible electrical issue but incredibly easy to fix properly or just with a zip tie to troubleshoot. I doubt it is anything else electrical, as they really only need two hot wires to work - 12 volt ignition to the distributor and starter crank power, the rest are just accessories. It could also be the speed the choke is opening, possibly to soon? Adjusted by turning the black disk on the side clockwise or counterclockwise.
Timing is at 8....that's 8 degrees with no vac advance or total? Idle total advance, vac + mech should be in the 25-40* range, usually the more the better, I dont know offhand what a 360 and your cylinder heads like but in that range.
even if there is a huge vacuum leak, the miss should go away at WOT / zero vacuum.
Keep in mind;
Idle screws are idle af ratio
mid range power is primaries and the idle mixture together. Not just primaries.
WOT is idle mixture + primaries + secondary's. All three combined, plus the accelerator pumps if you really got on it.
A properly tuned 360 should be able to really test your AMC 20 2 piece axle strength on pavement if you still have that rear-end.
My services can be available with a complete holly jet kit, timing lights, vac gauges etc for a small fee
plus I cant even remember what a CJ7 is supposed to look like anymore. I have spent enough time and money tuning a carb I could have changed over to fuel injection now but that's another story. 6
Tech Talk / Re: AMC 360 misfire
« Last post by Zooguy on January 12, 2021, 04:08:01 PM »Thanks for the suggestions. I feel like it is now the carb also. I don’t have a vacuum gauge but maybe I should get one. The plugs when I last pulled them looked good. I should try again though. I am pretty sure I don’t have vacuum leaks. And I have replaced the fuel lines with braided line and as far away from the exhaust as I can. I also put in a carb spacer incase it was transferring heat.
For my cam I actually put in a tamer one. It had one with a 292 open duration so I replaced it with a 252. It will mostly be a pavement queen.
Any suggestions on good mechanics to adjust the carb? I am ok with throwing a bit of money at it if I can’t figure it out. Again thanks for the input.
For my cam I actually put in a tamer one. It had one with a 292 open duration so I replaced it with a 252. It will mostly be a pavement queen.
Any suggestions on good mechanics to adjust the carb? I am ok with throwing a bit of money at it if I can’t figure it out. Again thanks for the input.
7
Tech Talk / Re: AMC 360 misfire
« Last post by cLAY on January 12, 2021, 01:49:27 AM »Everything here sounds to me like a carb issue, not spark. Especially cranking down the mixture screws not having much effect. Do you have a vacuum guage? Thats the best way of tuning a carb short of putting an O2 sensor in the exhaust. Without one your best best is to tune mixture screw for highest idle, reset idle screw, recheck timing, then reset mixture screw again and recheck everything still it stays the same. Also make sure the choke is fully opening.
Pull the plugs, sooty black-running rich
Check for vacuum leaks, brake booster diaphram and distributor vacuum line are often overlooked culprits.
Fuel boiling in the lines or carb bowls can cause theses symptoms as well. Does it have a fuel return? Lines routed too close to exhaust.
I don't know anything about the Holley quickshot, but I played with lots of older Holleys. Pain in the arse, everyone of them. Way too much adjustability and super finicky. Floats bounced on every big bump offroad causing a floodout, Steep climbs caused bowls to overflow, floodout. Had to rest mixture and choke settings at every season change. Tried all sorts of tricks, spring loaded needle and seats, overflow tubes, etc. Ended up going to an Edelbrock Truck Avenger carb and having WAY less issues.
What did you put in for a cam? Anything radical? Still idles nice or lopes?
Pull the plugs, sooty black-running rich
Check for vacuum leaks, brake booster diaphram and distributor vacuum line are often overlooked culprits.
Fuel boiling in the lines or carb bowls can cause theses symptoms as well. Does it have a fuel return? Lines routed too close to exhaust.
I don't know anything about the Holley quickshot, but I played with lots of older Holleys. Pain in the arse, everyone of them. Way too much adjustability and super finicky. Floats bounced on every big bump offroad causing a floodout, Steep climbs caused bowls to overflow, floodout. Had to rest mixture and choke settings at every season change. Tried all sorts of tricks, spring loaded needle and seats, overflow tubes, etc. Ended up going to an Edelbrock Truck Avenger carb and having WAY less issues.
What did you put in for a cam? Anything radical? Still idles nice or lopes?
8
Tech Talk / Re: AMC 360 misfire
« Last post by Zooguy on January 09, 2021, 08:08:57 PM »Checked the wiring today and it seemed to help. I solder a few that looked weak. It was one of my better test drives. I thought I would try to adjust the carb while i was at it and noticed something a bit strange. I can tighten the idle screws on either side of the carb all the way and it doesn’t stall. Why is that? High speed feels better and I turned the secondary screw out a bit. The only time the jeep seemed to have trouble is when I gave it too much gas too quickly. It then stuttered and I had to back off. It will get to speed but I have to get it there slowly. But a step in the right direction.
9
Tech Talk / Re: AMC 360 misfire
« Last post by Vinman on January 08, 2021, 10:06:47 PM »I think you’re on the right track with it being and electrical issue. Keep plugging away and check every electrical connection you can find. Maybe start shaking all the wiring harnesses while it’s running to see if you can replicate it.
Just spit-balling here but maybe spray water over all the engine electrical connections with the engine running to see if you can find a weak link?
Just spit-balling here but maybe spray water over all the engine electrical connections with the engine running to see if you can find a weak link?
10
Tech Talk / Re: AMC 360 misfire
« Last post by Zooguy on January 08, 2021, 08:59:19 PM »I’ve been searching the web and maybe a loose Tach wire is causing it...maybe. I’ll check tomorrow.
